ABB - Low Voltage Drives ACS800-37-1330-5+C129+H359+Q950+Q951 - CABINET DRIVE ULTRA LOW HARMONIC, Product Family: ACS800, Horsepower: 1250 HP, Output Current: 1476 A, Voltage: 480 VAC, Voltage Range: 380-500V, NEMA 1 / UL Type 1 (IP21), Floor-mounted, Local or Remote Mounted LCD Display and Keypad, 3-Phase Input, 3-Phase Output, Frame: 3xR8i, Product HxWxD: 91.1 in x 139 in x 25.4 in, Product Weight: 6746 lbs

ABB Low Voltage Drives ACS800-37-1330-5+C129+H359+Q950+Q951 CABINET DRIVE ULTRA LOW HARMONIC, Product Family: ACS800, Horsepower: 1250 HP, Output…

Alternate Item Number: 3AUA0000050672

UPC: 662348055717


Documents & Media
Specification Sheet

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB ACS800-37-1330-5 is a high-performance industrial drive designed for demanding applications requiring ultra-low harmonic distortion. With a robust 1250 HP capacity and 1476 A output current, this drive operates efficiently within a 380-500VAC voltage range, ensuring reliable performance in diverse industrial environments. Its NEMA 1 (IP21) enclosure provides protection against dust and debris, while the floor-mounted design optimizes space utilization. Featuring a local or remote-mounted LCD display and keypad, the ACS800-37-1330-5 offers intuitive control and monitoring capabilities. Ideal for heavy-duty applications in manufacturing, oil and gas, and water treatment, this drive delivers exceptional energy efficiency and operational reliability. The 3-phase input and output ensure seamless integration with existing systems, while its compact yet durable frame (3xR8i) ensures long-term performance. Weighing 6746 lbs, this drive is engineered for stability and durability in harsh industrial settings.
  • 1250 HP industrial drive with 1476 A output current for high-power applications
  • Ultra-low harmonic distortion for improved power quality and efficiency
  • Operates within 380-500VAC voltage range with 480VAC nominal voltage
  • NEMA 1 (IP21) enclosure for protection against dust and debris
  • Local or remote-mounted LCD display and keypad for intuitive control and monitoring
Double plastic fiber optic, Qty 1, 5 meters long

61059113

Double plastic fiber optic, Qty 1, 5 meters long
The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.

FENA-21

The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.
600V Class Iron Core Reactor, Core and Coil, 11 Amps, 2.57 Inductance, 60 Hz

CRX0011AC

600V Class Iron Core Reactor, Core and Coil, 11 Amps, 2.57 Inductance, 60 Hz
KDR, 208V, 19A, 5HP

KDRB22L

KDR, 208V, 19A, 5HP

Frequently Asked Questions

What is the standard protection class for the ACS800-37?

The standard protection class for the ACS800-37 is UL Type 1.

Does the ACS800-37 include a built-in low harmonic filter?

Yes, it features a built-in low harmonic LCL filter.

What motor control technology does the ACS800-37 use?

It utilizes ABB's exclusive Direct Torque Control (DTC) for speed and torque control.

What is the purpose of the ACS800-37 drive?

The ACS800-37 drive is designed to eliminate low and high order harmonics, meeting strict standards like IEEE519 without external filtering equipment.

What is the maximum altitude for operation without derating?

The drive can operate up to 1000 meters without derating.

What is the relative humidity limit for operation?

The relative humidity must be between 5% and 95%, with no condensation allowed.

How does the ACS800-37 compare to external harmonic solutions?

It is simpler, more compact, and offers better harmonic performance than 12- and 18-pulse solutions, avoiding the need for dedicated multi-pulse transformers.

What is the operating temperature range for the ACS800-37?

The operating temperature range is -15 to +50°C, with reduced output current above 40°C.

What are the available supply voltage ranges for the ACS800-37?

It supports 3-phase supply voltages of 208-240V, 380-500V, and 525-690V.

Can the ACS800-37 handle AC line voltage imbalances?

Yes, it is impervious to AC line voltage imbalances up to and over 3%.
