ABB - Low Voltage Drives
ACS800-37-0070-5+C129
Alternate Item Number: 3AUA0000051385
UPC: 662348053195
Documents & Media
Contact for Pricing
Overview
The ABB ACS800-37-0070-5+C129 is a 75 HP, 114A, 480VAC ultra-low harmonic cabinet drive designed for industrial applications. This floor-mounted unit features a NEMA 1 (UL Type 1, IP21) enclosure, providing protection against dust and light splashes. It operates within a 380-500V range, ensuring compatibility with standard industrial power supplies. The drive offers flexible control with a local or remote mounted LCD display and keypad. Its 3-phase input and 3-phase output facilitate integration into existing motor control systems. Constructed with a robust R6 frame, the drive measures 91.1 inches in height, 16.9 inches in width, and 25.4 inches in depth, with a total weight of 662 lbs. The ACS800 series is known for its ability to minimize harmonic distortion, contributing to a cleaner power grid and improved system efficiency. This specific model, SKU ACS800-37-0070-5+C129, is manufactured by ABB Low Voltage Drives in Denmark. Ideal for applications requiring precise motor speed and torque control while adhering to strict harmonic emission standards.
- 75 HP, 114A, 480VAC Ultra Low Harmonic Cabinet Drive
- NEMA 1 (UL Type 1, IP21) Enclosure for Dust and Light Splash Protection
- Floor-Mounted Design with Local/Remote LCD Display and Keypad
- 3-Phase Input / 3-Phase Output for System Integration
- ABB Low Voltage Drives, R6 Frame, 380-500V Operating Range
Specifications
Connection Type | 3-Phase Input, 3-Phase Output |
Connection Type | 3-phase |
Current Rating | 114 A |
IP Rating | IP21 |
Mounting Type | Floor-mounted |
NEMA Rating | Type 1 |
Nema Rating | NEMA 1 |
Poles | 3-Phase |
Series | ACS800 |
Size | 91.1 in x 16.9 in x 25.4 in |
Voltage Rating | 480 VAC |
FENA-21
The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.
