ABB - Low Voltage Drives
ACS550-U1-125A-6+B055
Alternate Item Number: 3AUA0000009610
UPC: 662348050279
Documents & Media
Contact for Pricing
Overview
The ABB ACS550-U1-125A-6+B055 is a robust AC drive engineered for reliable motor control in industrial settings. This unit features a substantial 125HP power rating and a 125A current capacity, designed to operate with input voltages ranging from 500 to 600 VAC. Its construction adheres to NEMA Type 12 and IP55 enclosure standards, providing effective protection against dust ingress and water jets, making it suitable for challenging environments. The drive offers a 1.1 overload capability, ensuring consistent performance even under increased load conditions. With advanced control algorithms and an intuitive interface, the ACS550 series facilitates precise motor speed and torque management, contributing to enhanced operational efficiency and potential energy savings. Its compact dimensions of 36.4 x 16.1 x 16.7 inches and wall-mounting design simplify installation in various industrial layouts. Ideal for applications within manufacturing, material handling, and HVAC systems, the ACS550-U1-125A-6+B055 from ABB Low Voltage Drives is built for durability and sustained operational reliability. This drive is a key component for optimizing motor performance and reducing operational costs in demanding industrial processes. The UNSPSC code for this product is 39122001, and it is manufactured in Denmark.
- 125HP / 125A power and current rating for demanding applications
- 500-600 VAC input voltage compatibility
- NEMA Type 12 / IP55 enclosure for dust and water protection
- 1.1 overload capability for enhanced performance
- Wall-mount design for flexible installation
Specifications
Control Panel | Advanced |
Frame Size | R6 |
Input Phase | 3-Phase |
IP Rating | IP55 |
Output Current | 125 |
Output Phase | 3-Phase |
UL Type | 12 |
Voltage | 600 |
Voltage Range | 500-600 |
Package Dimensions (L x W x H) | 16.7 in x 16.1 in x 36.4 in |
Package Dimensions (L x W x H) | 42.418 cm x 40.894 cm x 92.456 cm |
Package Weight (Imperial) | 190.000 L |
Package Weight (Metric) | 86.184 kg |
FENA-21
The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.
