ABB - Low Voltage Drives
ACS550-U1-059A-4+B055+K466
Alternate Item Number: 3AUA0000055991
UPC: 662348048467
Documents & Media
Contact for Pricing
Overview
The ABB ACS550-U1-059A-4+B055+K466 is a robust industrial AC drive designed for precise motor control in demanding applications. This unit operates with a 3-phase input voltage range of 380-480V and delivers 40 horsepower to motors, with a maximum output current of 59A. Its enclosure is rated IP55 and NEMA Type 12, providing protection against dust ingress and low-pressure water jets, making it suitable for harsh industrial environments. The drive features a 1.1 overload capacity, ensuring reliable operation during temporary current surges and protecting connected equipment. Measuring 29.9 x 10.1 x 11.2 inches, its compact design facilitates easy wall mounting. Advanced connectivity is provided through integrated Ethernet ports supporting Modbus/TCP and EtherNet/IP protocols, enabling straightforward integration into modern automation systems and networks. This drive is ideal for applications such as pumps, fans, conveyors, and other machinery requiring variable speed control and energy efficiency. ABB's commitment to quality and reliability ensures consistent performance and reduced operational costs. The UNSPSC code for this product is 39122001, and it is manufactured in Denmark (DK).
- 3-Phase Input Voltage: 380-480V
- Motor Power: 40HP
- Max Output Current: 59A
- Enclosure Rating: IP55 / NEMA Type 12
- Connectivity: Ethernet (Modbus/TCP, EtherNet/IP)
Specifications
Control Panel | Advanced |
Frame Size | R4 |
Input Phase | 3-Phase |
IP Rating | IP55 |
Options | Ethernet (Modbus/TCPEtherNet/IP) |
Output Current | 59 |
Output Phase | 3-Phase |
UL Type | 12 |
Voltage | 480 |
Voltage Range | 380-480 |
Package Dimensions (L x W x H) | 11.2 in x 10.1 in x 29.9 in |
Package Dimensions (L x W x H) | 28.448 cm x 25.654 cm x 75.946 cm |
Package Weight (Imperial) | 75.000 L |
Package Weight (Metric) | 34.020 kg |
FENA-21
The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.
