ABB - Low Voltage Drives ACS550-PD-246A-4 - GENERAL PURPOSE PACKAGED DRIVE W/ DISCONNECT SWITCH AND FUSES, Product Family: ACS550, Horsepower: 200 HP, Output Current: 245 A, Voltage: 480 VAC , Voltage Range: 380-480V, NEMA 1 / UL Type 1 (IP21), Mounting: Wall-mounted, Advanced Control Panel, 3-Phase Input, 3-Phase Output, Frame: R6, Product HxWxD: 47.7 in x 28.1 in x 19 in, Product Weight: 359 lbs
ABB - Low Voltage Drives

ACS550-PD-246A-4

Alternate Item Number: 3AUA0000046713

UPC: 662348045862

Documents & Media
Specification Sheet

Contact for Pricing

Overview

The ABB ACS550-PD-246A-4 is a general-purpose packaged drive designed for reliable industrial motor control. This unit delivers 200 HP output with a 245 Amp rating, operating on a 480 VAC, 3-phase input with a voltage range of 380-480V. The NEMA 1 / UL Type 1 (IP21) enclosure protects against dust and light water ingress, making it suitable for harsh industrial environments. This 3-phase input to 3-phase output drive includes an integrated disconnect switch and fuses for enhanced safety. The advanced control panel simplifies operation and setup, while the wall-mounted design optimizes space in manufacturing, HVAC, and process industries. Key specifications include a frame size of R6, dimensions of 47.7" H x 28.1" W x 19" D, and a weight of 359 lbs. Ideal for applications requiring efficient motor speed regulation and energy savings, the ACS550-PD-246A-4 ensures consistent performance with minimal maintenance.
  • 200 HP motor rating with 245 Amp output current
  • 480 VAC 3-phase input, voltage range 380-480V
  • NEMA 1 / UL Type 1 (IP21) enclosure for dust and light water protection
  • Integrated disconnect switch and fuses for enhanced safety
  • Wall-mounted design with advanced control panel for easy setup

Specifications

Current Rating
245 A
IP Rating
IP21
Mounting Type
Wall-mounted
Nema Rating
NEMA 1 / UL Type 1
Series
ACS550
Size
47.7 in H x 28.1 in W x 19 in D
Voltage Rating
480 VAC
Double plastic fiber optic, Qty 1, 5 meters long

61059113

Double plastic fiber optic, Qty 1, 5 meters long
The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.

FENA-21

The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.
600V Class Iron Core Reactor, Core and Coil, 11 Amps, 2.57 Inductance, 60 Hz

CRX0011AC

600V Class Iron Core Reactor, Core and Coil, 11 Amps, 2.57 Inductance, 60 Hz
KDR, 208V, 19A, 5HP

KDRB22L

KDR, 208V, 19A, 5HP
