ABB - Low Voltage Drives
ACS550-PD-078A-4+B055+K451
Alternate Item Number: 3AUA0000052383
UPC: 662348045169
Documents & Media
Contact for Pricing
Overview
The ABB ACS550-PD-078A-4+B055+K451 is a 60 HP general-purpose packaged drive designed for industrial motor control applications. This 480VAC drive delivers 77A output current, operating within a 380-480VAC input range. The NEMA 12 / UL Type 12 (IP54) enclosure provides protection against dust and moisture ingress, making it suitable for harsh industrial environments. Key features include an integrated disconnect switch and fuses for enhanced safety and maintenance convenience. The device supports 3-phase input and output, with a wall-mounted design and compact R4 frame dimensions of 45.8 in x 10.5 in x 13.1 in (HxWxD), weighing 99 lbs. The advanced control panel offers intuitive operation, while the DeviceNet adapter enables seamless integration with industrial automation networks. Designed for reliability and efficiency, this ABB drive is ideal for general-purpose applications requiring precise motor control and robust protection.
- 60 HP / 45 kW motor rating
- 480 VAC, 77 A output current
- NEMA 12 / UL Type 12 (IP54) enclosure
- Integrated disconnect switch and fuses
- DeviceNet adapter for network integration
- Advanced control panel for precise motor control
- 3-phase input and output compatibility
Specifications
Connection Type | 3-phase |
Current Rating | 77 A |
IP Rating | IP54 |
Mounting Type | Wall-mounted |
Nema Rating | NEMA 12 |
Series | ACS550 |
Size | 45.8 in x 10.5 in x 13.1 in |
Voltage Rating | 480 VAC |
Package Dimensions (L x W x H) | 58 IN x 14 IN x 19 IN |
Package Dimensions (L x W x H) | 147.32 cm x 35.56 cm x 48.26 cm |
FENA-21
The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.
