ABB - Low Voltage Drives ACS550-PD-059A-2 - GENERAL PURPOSE PACKAGED DRIVE W/ DISCONNECT SWITCH AND FUSES, Product Family: ACS550, Horsepower: 20 HP, Output Current: 59.4 A, Voltage: 240 VAC, Voltage Range: 208-240V, NEMA 1 / UL Type 1 (IP21), Mounting: Wall-mounted, Advanced Control Panel, 3-Phase Input, 3-Phase Output, Frame: R3, Product HxWxD: 39.9 in x 10.2 in x 11.9 in, Product Weight: 75 lbs

ABB Low Voltage Drives ACS550-PD-059A-2 GENERAL PURPOSE PACKAGED DRIVE W/ DISCONNECT SWITCH AND FUSES, Product Family: ACS550…

Alternate Item Number: 3AUA0000010283

UPC: 662348044711

Documents & Media
Specification Sheet

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB ACS550-PD-059A-2 is a general-purpose packaged drive designed for reliable industrial motor control. This 20 HP drive operates on a 208-240V, 3-phase input and delivers an output current of 59.4A. It features a NEMA 1 / UL Type 1 (IP21) enclosure, suitable for wall mounting and protection against dust and light splashing. The integrated disconnect switch and fuses enhance operational safety and simplify maintenance. Key Specifications: - SKU: ACS550-PD-059A-2 - Manufacturer: ABB - Low Voltage Drives - Product Family: ACS550 - Horsepower: 20 HP - Output Current: 59.4 A - Voltage: 240 VAC - Voltage Range: 208-240V - Enclosure: NEMA 1 / UL Type 1 (IP21) - Mounting: Wall-mounted - Control Panel: Advanced - Input/Output: 3-Phase - Frame Size: R3 - Dimensions (HxWxD): 39.9 in x 10.2 in x 11.9 in - Weight: 75 lbs This drive is ideal for applications in manufacturing, HVAC, and material handling where precise motor speed control, energy efficiency, and durability are critical. The ACS550-PD-059A-2 offers straightforward installation and operation with its advanced control panel. Trust ABB's expertise in low-voltage drives to optimize your industrial processes with this versatile and dependable solution. The product originates from DK.
  • 20 HP, 59.4A, 208-240V, 3-Phase Input/Output
  • NEMA 1 / UL Type 1 (IP21) Enclosure for protection
  • Integrated disconnect switch and fuses for safety
  • Wall-mounted design with advanced control panel
  • Ideal for manufacturing, HVAC, and material handling

Specifications

Package Dimensions (L x W x H)
58 IN x 14 IN x 19 IN
Package Dimensions (L x W x H)
147.32 cm x 35.56 cm x 48.26 cm
Double plastic fiber optic, Qty 1, 5 meters long

61059113

Double plastic fiber optic, Qty 1, 5 meters long
The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.

FENA-21

The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.
600V Class Iron Core Reactor, Core and Coil, 11 Amps, 2.57 Inductance, 60 Hz

CRX0011AC

600V Class Iron Core Reactor, Core and Coil, 11 Amps, 2.57 Inductance, 60 Hz
KDR, 208V, 19A, 5HP

KDRB22L

KDR, 208V, 19A, 5HP

Frequently Asked Questions

What are the voltage and power ranges for ABB ACS550 standard drives?

The drives are available in 3-phase options: 208-240V (0.75-100Hp), 380-480V (1-550Hp), and 500-600V (1.5-150Hp).

What is the operating frequency range for the ACS550 drives?

The input power frequency range is 48 to 63 Hz, and the motor connection frequency range is 0 to 500 Hz.

What is the power factor of the ACS550 drives?

The power factor for the ACS550 drives is 0.98.

Does the ACS550 have built-in serial communication capabilities?

Yes, the ACS550 drives have built-in Modbus RTU protocol for serial communication via RS 485.

What product approvals does the ACS550 series have?

The ACS550 series holds UL, cUL, CSA, CE, C-TICK, and GOST-R approvals depending on the voltage rating.

What NEMA enclosure types are available for ACS550 wall-mount units?

ACS550 wall-mount units are available in NEMA 1, 12, and 3R enclosures.

What are the acceleration and deceleration time limits for ACS550 drives?

Acceleration and deceleration times can be set between 0.1 to 1800 seconds.

What types of analog inputs are available on the ACS550 drives?

The drives feature two analog inputs that accept voltage signals (0-10V) or current signals (0-20mA).

What are the specifications for the analog outputs on ACS550 drives?

There are two analog outputs providing 0-20mA signals with an accuracy of ±3% and a load capacity of less than 500 Ω.

What is the auxiliary voltage provided by the ACS550 drives?

The drives provide an auxiliary voltage of 24V DC ±10% with a maximum current of 250 mA.
