ABB Low Voltage Drives ACS550-PD-038A-4 GENERAL PURPOSE PACKAGED DRIVE W/ DISCONNECT SWITCH AND FUSES, Product Family: ACS550…

Name: ABB ACS550-PD-038A-4 25 HP, 38A, 480VAC general-purpose drive with disconnect and fuses, NEMA 1.
Brand: ABB - Low Voltage Drives
SKU: ACS550-PD-038A-4
Availability: InStock

Alternate Item Number: 3AUA0000010299

UPC: 662348044308

Documents & Media

Specification Sheet

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB ACS550-PD-038A-4 is a wall-mounted, general-purpose packaged AC drive designed for reliable motor control in industrial applications. This 25 HP drive delivers 38A output current at 480VAC (380-480V range) with 3-phase input and output, making it ideal for pumps, fans, conveyors, and other variable-speed machinery. The NEMA 1 / UL Type 1 (IP21) enclosure provides protection against dust and light splashes, while the integrated disconnect switch and fuses enhance safety and simplify maintenance. The advanced control panel enables precise speed and torque adjustments, and the compact dimensions (39.9" x 10.2" x 11.9") and 75 lbs weight allow installation in space-constrained environments. Compatible with ABB’s ACS550 product family, this drive offers energy-efficient operation with built-in overload protection to extend motor life. The R3 frame design ensures compatibility with standard industrial mounting configurations. With a power factor of 0.98, frequency range of 48-63 Hz, and programmable acceleration/deceleration times from 0.1 to 1800 seconds, the ACS550-PD-038A-4 provides flexible control for demanding applications. Built-in Modbus RTU via RS485 enables easy integration with industrial control systems. The drive supports motor frequencies from 0 to 500 Hz and includes 24V DC auxiliary voltage (250mA max) for external devices. With a 1.1 overload rating, it safeguards connected equipment from temporary current spikes, extending component life.

25 HP output at 38A, 480VAC (380-480V range), 3-phase input/output
NEMA 1 / UL Type 1 (IP21) enclosure for dust and splash protection
Integrated disconnect switch and fuses for enhanced safety and simplified maintenance
Advanced control panel with programmable acceleration/deceleration (0.1-1800s)
Compact R3 frame (39.9" x 10.2" x 11.9"), 75 lbs, wall-mountable
Built-in Modbus RTU via RS485 for industrial communication
24V DC auxiliary voltage (250mA max) for external devices
Power factor 0.98, frequency range 48-63 Hz, motor frequency 0-500 Hz
1.1 overload rating for equipment protection and extended motor life

Specifications

Package Dimensions (L x W x H)	58 in x 14 in x 19 in
Package Dimensions (L x W x H)	147.32 cm x 35.56 cm x 48.26 cm
Package Weight (Imperial)	92.000 L
Package Weight (Metric)	41.731 kg

CRX0011AC

600V Class Iron Core Reactor, Core and Coil, 11 Amps, 2.57 Inductance, 60 Hz

61059113

Double plastic fiber optic, Qty 1, 5 meters long

FENA-21

The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.

KDRB22L

KDR, 208V, 19A, 5HP

PS-60

Power supply for DIN-rail

0626030563

BK63H 1P B2A 10kA 120/240VAC UL1077

0706001600

MMS-63H 40A EXP

1338006700

MC-50a AC120V 50/60Hz SCREW 1a1b (Metasol) EXP (MC50A-30-11-K7-S-E)

1270040900

GMD-16M DC240V 3W 1b EXP (GMD16M-30-01-UD-3W-S-E)

1SNK705010R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

CR324E610F

General Electric Control Products. Nema Power Devices. Ol Relay 610F8364

XT2NU3090BFF000XXX

C.BREAKER TMAX XT2N 125 UL/CSA FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 90 I3=450...900 A

MPET4-10R

Modular Emergency Stop - Twist release - Mushroom 40mm - Red - Non-illuminated - - No contact block

NNC75X75WH2

The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.

3194213000K04

DS9 RECEPTACLE POLY BLUE SIZE 5 IP 66/67/69 3P+G 150 A 480 VAC 60 Hz

C2G0150MQMJ

HPS Open Style Control Transformer, 150VA 240x480V-120x240V 50/60Hz

ACS800-U31-0050-5+E202+K458

WALL-MOUNTED DRIVE ULTRA LOW HARMONIC , Product Family: ACS800, Horsepower: 50 HP, Output Current: 67 A, Voltage: 480 VAC, Voltage Range: 380-500V, NEMA 1 / UL Type 1 (IP21), Wall-mounted, Local or Remote Mounted LCD Display and Keypad, ModBus Adapter, EMC/RFI Filter (1st Envir), 3-Phase Input, 3-Phase Output, Frame: R5, Product HxWxD: 32.12 in x 10.43 in x 15.35 in, Product Weight: 144 lbs

135N1761

VLT® Midi Drive FC 280, 4.0 kW / 5.5 HP, 3 x 380/480V AC, IP21/Type 1, RFI-Filter, Class A2 (C3), Brake IGBT, Numerical LCP, Standard cable entries, Modbus RTU, 8.2 A continuous, frame K2

CFW500C04P3T5DB20

DRIVE CFW500C04P3T5DB20 WEG specifications: Power supply 500-600 V; Input phases Three-phase; Configuration With options; Rated current (HD) 4.3 A; RFI filter Without filter; Enclosure IP20; Dynamic braking Standard with braking; Safety Stop Not available; Control method - induction motor V/f, VVW, Sensorless, Encoder and VVW PM; Rated efficiency ≥ 97%; Link Inductor No; Conformal Coating 3C2 (IEC 60721-3-3:2002); SoftPLC Yes, incorporated; Temperature -10 °C a 50 °C; USB port Only with plug-in; Memory card Not included in the product; I/O standard 4 x DI; 1 relé NA/NF e 1 transistor x DO; 1 x AI; 1 x AO.; Display Numeric LCD

Frequently Asked Questions

What is the voltage and power range for 3-phase input?

For 3-phase, the voltage ranges are 208-240V (0.75-100Hp), 380-480V (1-550Hp), and 500-600V (1.5-150Hp).

What serial communication protocol is built-in?

The drive has a built-in Modbus RTU protocol for serial communication via RS 485.

What is the operating frequency range for the drives?

The input power frequency range is 48 to 63 Hz, and the motor connection frequency is 0 to 500 Hz.

How many digital inputs and relay outputs are included?

The drive has six digital inputs and three relay outputs.

What is the recommended ambient temperature range for operation?

The ambient temperature range for operation is 15 to 40°C (5 to 104°F).

What types of analog inputs are available?

There are two analog inputs that support voltage signals (0-10V) and current signals (0-20mA).

What are the product compliance and certifications?

The drives have UL, cUL, CSA, CE, C-TICK, and GOST-R approvals, and are seismic certified to ICC AC-156.

What are the acceleration and deceleration time limits?

Acceleration and deceleration times can be set between 0.1 to 1800 seconds.

What is the auxiliary voltage provided by the drive?

The drive provides an auxiliary voltage of 24 V DC ±10% with a maximum current of 250 mA.

What is the maximum allowable relative humidity?

The relative humidity should be lower than 95%, without condensation.
