ABB - Low Voltage Drives ACS550-PC-075A-2 - GENERAL PURPOSE PACKAGED DRIVE W/ CIRCUIT BREAKER DISCONNECT, Product Family: ACS550, Horsepower: 25 HP, Output Current: 74.8 A, Voltage: 240 VAC, Voltage Range: 208-240V, NEMA 1 / UL Type 1 (IP21), Mounting: Wall-mounted, Advanced Control Panel, 3-Phase Input, 3-Phase Output, Frame: R4, Product HxWxD: 45.2 in x 10.2 in x 13.1 in, Product Weight: 95 lbs

ABB Low Voltage Drives ACS550-PC-075A-2 GENERAL PURPOSE PACKAGED DRIVE W/ CIRCUIT BREAKER DISCONNECT, Product Family: ACS550…

Alternate Item Number: 3AUA0000010234

UPC: 662348042434

Documents & Media
Specification Sheet

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB ACS550-PC-075A-2 is a general-purpose packaged AC drive designed for industrial motor control applications requiring reliable 25 HP (74.8A) operation. This drive operates within a 208-240VAC input range, making it suitable for standard industrial power systems. The NEMA 1 / UL Type 1 (IP21) enclosure provides basic protection against dust and light splashes, while the wall-mounted design optimizes space efficiency in control rooms or production floors. Key features include an integrated circuit breaker disconnect for safe power isolation and an advanced control panel for local operation and configuration. The 3-phase input/output design ensures compatibility with standard industrial motors, while the R4 frame size (45.2 x 10.2 x 13.1 inches, 95 lbs) allows for compact installation in tight spaces. This drive is part of ABB's ACS550 family, known for its robust construction and energy-efficient operation. Ideal applications include HVAC systems, pumps, fans, conveyors, and process automation where precise speed control and reliable operation are critical. The drive's compatibility with 3-phase 208-240VAC power systems makes it a versatile choice for facilities upgrading or replacing older motor control systems. With ABB's reputation for quality and reliability, the ACS550-PC-075A-2 provides a dependable solution for industrial motor control needs.
  • 25 HP (74.8A) output for industrial motor control
  • 208-240VAC input range with 3-phase compatibility
  • NEMA 1 / UL Type 1 (IP21) enclosure for basic protection
  • Integrated circuit breaker disconnect for safe power isolation
  • Wall-mounted design with compact R4 frame (45.2 x 10.2 x 13.1 in, 95 lbs)

Specifications

Connection Type
3-Phase Input, 3-Phase Output
Current Rating
74.8 A
IP Rating
IP21
Mounting Type
Wall-mounted
Nema Rating
NEMA 1 / UL Type 1
Poles
3-Phase
Series
ACS550
Size
45.2 in x 10.2 in x 13.1 in
Voltage Rating
208-240 VAC
Package Dimensions (L x W x H)
58 IN x 14 IN x 19 IN
Package Dimensions (L x W x H)
147.32 cm x 35.56 cm x 48.26 cm
600V Class Iron Core Reactor, Core and Coil, 11 Amps, 2.57 Inductance, 60 Hz

CRX0011AC

600V Class Iron Core Reactor, Core and Coil, 11 Amps, 2.57 Inductance, 60 Hz
Double plastic fiber optic, Qty 1, 5 meters long

61059113

Double plastic fiber optic, Qty 1, 5 meters long
The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.

FENA-21

The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.
KDR, 208V, 19A, 5HP

KDRB22L

KDR, 208V, 19A, 5HP

Frequently Asked Questions

What is the input voltage range for ACS550 drives?

The drives support 3-phase input voltages of 208-240V, 380-480V, and 500-600V, with a tolerance of +10/-15%.

Does the ACS550 drive have an integrated EMC filter?

Yes, the ACS550 standard drives include an integral EMC filter as standard.

What is the operating frequency range for the motor connection?

The motor connection frequency range is from 0 to 500 Hz.

What are the standard communication protocols supported by ACS550 drives?

The drives have built-in Modbus RTU protocol and support numerous internally mountable fieldbus adapters.

What is the ambient temperature range for operating ACS550 drives?

The drives can operate in ambient temperatures between 15 to 40°C (5 to 104°F), with derating required from 40 to 50°C (104 to 122°F).

What are the available power ratings for the 3-phase, 380-480V range?

For 3-phase, 380 to 480V, the power range is from 1 to 550Hp.

What is the maximum switching voltage for the relay outputs?

The maximum switching voltage for the three relay outputs is 250V AC or 30V DC.

What is the power factor of the ACS550 drives?

The power factor is 0.98.

What types of enclosures are available for ACS550 drives?

Available enclosures include NEMA 1, 12, and 3R, depending on the specific ACS550 model and mounting type.

What is the maximum auxiliary voltage output for the drive?

The auxiliary voltage output is 24V DC ±10%, with a maximum current of 250 mA.
