ABB - Low Voltage Drives
ACS550-PC-052A-6
Alternate Item Number: 3AUA0000010269
UPC: 662348042038
Documents & Media
Contact for Pricing
Overview
The ABB ACS550-PC-052A-6 is a general-purpose packaged drive designed for reliable motor control in industrial applications. This 50 HP drive delivers 52A output current at 600VAC, supporting a voltage range of 500-600V. It features a 3-phase input and output configuration, ideal for wall-mounted installation in standard industrial environments.
The drive includes an integrated circuit breaker disconnect for enhanced safety and simplified maintenance. Its NEMA 1 / UL Type 1 (IP21) enclosure provides protection against dust and light splashing, ensuring durability in harsh conditions. The advanced control panel offers intuitive operation and monitoring capabilities.
With dimensions of 45.2 in x 10.2 in x 13.1 in and a weight of 95 lbs, the ACS550-PC-052A-6 fits standard mounting configurations with its R4 frame design. It is suitable for applications in manufacturing, HVAC, and process industries where precise motor control and operational reliability are critical. The drive supports 3-phase input/output and is manufactured by ABB in Denmark.
- 50 HP output with 52A at 600VAC (500-600V range)
- Integrated circuit breaker disconnect for safety and maintenance
- NEMA 1 / UL Type 1 (IP21) enclosure for dust and splash protection
- Wall-mounted installation with R4 frame design
- Advanced control panel for intuitive operation and monitoring
Specifications
Connection Type | 3-phase |
Connection Type | 3-Phase Input/Output |
Current Rating | 52 A |
IP Rating | IP21 |
Mounting Type | Wall-mounted |
NEMA Rating | Type 1 |
Nema Rating | NEMA 1 / UL Type 1 |
Poles | 3-Phase |
Series | ACS550 |
Size | 45.2 in x 10.2 in x 13.1 in |
Size | 45.2 x 10.2 x 13.1 in |
Voltage Rating | 600 VAC |
Voltage Rating | 500-600 VAC |
Package Dimensions (L x W x H) | 58 IN x 14 IN x 19 IN |
Package Dimensions (L x W x H) | 147.32 cm x 35.56 cm x 48.26 cm |
FENA-21
The FENA 21 DualPort module supports Three protocols Modbus-TCP, EtherNet/IP, and the PROFInet IO RT network. The Modbus-TCP protocol is simply the Modbus protocol used on top of Ethernet-TCP/IP. Modbus-TCP is an open Industrial Ethernet network which has been specified by the Modbus-IDA User Organization. EtherNet/IP is based on the Common Industrial Protocol (CIP), which is also the framework for both the ControlNet and DeviceNet network protocols. PROFInet IO RT is an open network based on the PI Organization standard.
