68324963

The ABB R7 bottom exit pedestal (SKU 68324963) is a specialized component designed for ABB low voltage drives. It facilitates reliable electrical connections with failsafe bi-directional cylinder-lift terminals at both the top and bottom. For currents exceeding 63 A, it incorporates cage terminals. Terminal sizes accommodate cables up to 25/25 mm² (IEC) or 18-4 AWG (UL/CSA up to 63 A), and busbar connections up to 10/10 mm² (IEC) or 18-8 AWG (UL/CSA up to 63 A). Installation is simplified via a fast clip device onto a 35 mm DIN rail, supporting any mounting position. Connections are made from top and bottom, with tool-free withdrawal from the busbar possible from the bottom (excluding 125 A models). Dimensions are compact: 85 x 69 x 35 mm (2P) and 85 x 69 x 70 mm (4P). This pedestal ensures efficient wiring and space-saving integration in industrial motor control applications.
